RC F

AN AGGRESSIVE PERFORMANCE
BUILT FOR RACE TRACKS.

Comfort & Design

  • BOLD STYLING

    The styling is bold and aggressive, with a domed hood, a deeper grille, unique fascia, flared fenders, and ample cooling ducts.

  • 19-INCH ALUMINUM WHEELS

    19-inch forged aluminum wheels shod with staggered Michelin Pilot Super Sport tires confidently grip the asphalt of your favorite roads.

  • LED TAILLIGHTS

    Arranged in a distinctive L-shaped Lexus design, the LED taillights emphasize a sharp look that identifies your vehicle as a Lexus, even at night.

  • INTELLIGENT DIAL DESIGN

    Completely digitized, the centrally mounted tachometer changes design according to drive mode, and expresses more LFA-inspired character in SPORT S and SPORT S+ modes.

  • HIGH VIBRANCE PAINT

    A new painting process achieves unprecedented vibrancy to highlight the sporty nature of the RC F.

Performance

  • UNDER THE HOOD

    The RC F is powered by a formidable new 5.0-liter V8 engine.

  • 8-SPEED SPORT DIRECT SHIFT

    An eight-speed sport direct-shift transmission features a clutch that locks the torque converter in gears two through eight under hard acceleration.

  • DRIVE MODE SELECT

    Select performance to match your driving style with four drive modes: NORMAL, ECO, SPORT S and SPORT S+.

  • INTELLIGENT TORQUE

    The Torque Vectoring Differential system delivers a natural driving response by intelligently transferring an appropriate amount of torque to each rear wheel.

  • UNDERBODY AERODYNAMICS

    Aero underbody construction and stabilizing fins are integrated into the undercarriage for complete aerodynamics and a low drag coefficient.

  • BRAKING POWER

    For powerful braking performance, the 309mm rotors were fine-tuned to ensure effective braking and control.

EXCLUSIVE TO RC F

  • V8 POWER

    The naturally aspirated V8 engine exudes characteristic smoothness, excellent response and powerful output worthy of a premium sports engine.

  • HONED SUSPENSION

    Each part of the suspension was exclusively designed, tuned to perfection, optimized for rigidity, and honed on various race circuits around the world.

  • LAP TIMER

    Turn on the F-exclusive lap timer function to measure your lap time, and have it displayed it in the middle of the center meter ring.

  • TORQUE DISTRIBUTION DISPLAY

    Even torque information is displayed - allowing you to see how much torque is direct to each rear wheel.

  • G-FORCE DISPLAY

    View critical information about the magnitude and direction of G-forces acting on the vehicle in the center meter ring.

Safety

  • PARKING ASSIST

    The parking assist monitor accurately guides your parking attempts by superimposing projected parking lines on the back camera’s video feed.

  • BLIND SPOT MONITOR

    Know when vehicles are approaching from behind, even at higher speeds, with the next-generation Blind Spot Monitor.

  • 8 SRS AIRBAGS

    Collision impact is reduced with eight SRS airbags lining the cabin. Front seat occupants get added knee protection. In the back, full length side curtain airbags keep rear outer passengers safe.

Specifications

TECHNICAL DATA

  • ENGINE

    Engine Type 2UR-GSE
    No. of Cyls. & Arrangement 8 cylinders, V type
    Valve Mechanism 32-valve DOHC with Dual VVT-i
    Bore x Stroke 94.0 x 89.5 mm
    Displacement 4,969 cc
    Compression Ratio 12.3 : 1
    Fuel Injection System EFI, D-4S
    Fuel Type Gasoline
    Max. Output 470 HORSEPOWER / 7100 rpm
    Max. Torque 530 Nm / 4,800 - 5,600 rpm
  • PERFORMANCE

    Max. Speed 270 km/h
    Max. Cruising Speed 240 km/h
    Acceleration 4.5 sec (0 - 100 km/h)
  • CHASSIS

    Transmission
    TMC Code Name AA80E
    Type Automatic
    Transmission Gear Ratio
    Suspension
    1st 4.596
    2nd 2.724
    3rd 1.863
    4th 1.464
    5th 1.231
    6th 1.000
    7th 0.824
    8th 0.685
    Reverse 2176
    Brake Type
    Front Ventilated Disc
    Rear Ventilated Disc
    Brake Size
    Front 380/34 mm (Diameter/Thickness)
    Rear 345/28 mm (Diameter/Thickness)
    Swept Area
    Front Inside 31/Outside 31 sq inches
    Rear Inside 14/Outside 13 sq inches
    Total Inside 45/Outside 44 sq inches
    Parking Brake Type of Control and Location Foot Pedal Type
    Suspension Type
    Front Double Wishbone
    Rear Multi-link
    Lock to Lock 2.84
    Min. Turning Radius
    Tire 5.4 m
    Body 5.7 m
    Power Steering Type Electric
  • MEASUREMENTS

    Overall
    Length 4,705 mm
    Width 1,845 mm
    Height 1,390 mm
    Wheelbase 2,730 mm
    Tread
    Front 1,555 mm
    Rear 1,560 mm
    Interior
    Length 1,835 mm
    Width 1,520 mm
    Height 1,120 mm
    Weight
    Curb Weight 1,780 - 1,860 kg
    Gross Vehicle Weight 2,250 kg
    Effective Head Room
    Front 960, 928 mm
    Rear 888, 878 mm
    Couple Distance 833 mm
    Seating Capacity 4 person
    Overhang (Curb Weight)
    Front 930 mm
    Rear 1,045 mm
    Coefficient of Drag -
    Min. Running Ground Clearance 130
    Location of Min. Running Ground Clearance Floor Under Cover
    Angle of Approach 12.4 degrees
    Angle of Departure 15.6 degrees
    EPA Passenger Volume 22.488 m3
    Trunk Space*6 366 l
    Fuel Tank Capacity 66 l

The models selected have the same features.

IN-VEHICLE EQUIPMENT

  • In-car Entertainment

    AM/FM 1-DVD 17SP (EMV, ML)
  • SAFETY

    Blind Spot Monitor
    Red Cross Traffic Alert
    Pre collision safety system
    All Speed Dynamic Radar Cruise Control
    Anti-lock Brake System (ABS)
    Traction control
    VDIM
    Lighting
    Front Fog Lamps LED
    Automatic HighBeam (AHB)
    Headlamps LED L Type
    Others
    Power Steering
    Integrated Sport Driving (ECO / NORMAL / SPORT)
    Back Monitor: Back Guide Monitor (EMV)
    EMVN Remote Controller (RHD, FOR EMV)

The models selected have the same features.

Vehicle specifications may vary by market. Contact your local dealer for more information.
