Comfort & Design
Optitron Technology, pioneered by Lexus, improves meter clarity with crystal-clear illumination on the dials and fully illuminated needles.
MARK LEVINSON 3D SURROUND SOUND SYSTEM
A 24-speaker system that includes speakers in the ceiling ensures unprecedented sonic quality in an accurate and enveloping soundstage.
LED TURN SIGNALS
Lexus’ all-LED turn signal is a powerful combination of 16 bulbs that emit a brilliant glow, yet artfully conceal their presence when turned off.
TAILORED FOR COMFORT
Seats feature a shiatsu massage function with ventilation to deliver a soothing and refreshing environment.
ADJUSTABLE POWER SUNSHADE
All rear seat windows have power sunshades for protection against the glaring sun, achieving optimal lighting for utmost comfort and privacy.
Rear seat passengers enjoy the comfort of an ottoman seat with adjustable seat cushions that support calves.
AUTO LIFT-UP FUNCTION
A Lexus-first air suspension system automatically raises the vehicle for passengers to enter and exit with comfort and ease.
LEXUS CLIMATE CONCIERGE
Extensive infrared sensors detect the body temperature of all occupants to enable precise climate control for each passenger.
HANDS-FREE POWER TRUNK LID
A sensor underneath the rear bumper allows you to effortlessly open and close the trunk lid with a simple sweep of your feet.
UNDER THE HYBRID HOOD
Under the skin of the LS 500h is a hybrid powertrain consisting of a 3.5-liter V6 engine mated to two electric motors.
Artificial Intelligence Shift uses information from the G sensor to understand when to introduce downshift when braking, and how many gears to drop down.
DRIVE MODE SELECT
Select performance to match your driving style with six drive modes: NORMAL, ECO, COMFORT, SPORT S, SPORT S+, and Custom.
ADAPTIVE VARIABLE SUSPENSION
AVS continually adjusts shock-absorber damping rates while driving, delivering the type of smooth ride expected of a Lexus.
EXCLUSIVE TO LS 500h
LEXUS HYBRID DRIVE
Lexus Hybrid Drive draws power from both electric and petrol motors, resulting in instant torque and surprising acceleration.
EV DRIVE MODE
At low speeds, EV drive mode uses an electric motor for a silent and zero-emission drive.
When braking or decelerating, kinetic energy which would otherwise be lost is recovered as electric energy, and stored for later use.
FROM TACH TO ECO METER
In the mood for a sportier drive? The Hybrid System Indicator changes to a tachometer when you select SPORT mode.
MULTI-STAGE HYBRID SYSTEM
Our Hybrid Synergy Drive has a 4-speed shiftdevice that behaves like a 10-speed dual clutch transmission to deliver seamless acceleration.
14 SRS AIRBAGS
Collision impact is greatly reduced with 14 sensor-controlled SRS airbags lining the cabin, providing enhanced protection for all occupants.
BLIND SPOT MONITOR
Know when vehicles are approaching from behind, even at higher speeds, with the next-generation Blind Spot Monitor.
A combination of features accurately guides your parking attempts and provides additional driving and braking force to prevent any collisions.
View the status of your navigation system, or check on fuel economy and the air-conditioning all on one fully customizable, 12.3-inch display.
Engine Type Hybrid V6, 24 Valve DOHC with Dual VVT-i Displacement 3,456 cc Fuel System Premium Unleaded Gasoline Max. Output 356 BHP (Combined)
Max. Speed 250 km/h Max. Torque 350 Nm / 4,000 rpm Acceleration 5.1 sec (0 - 100 km/h)
Transmission Type Multi-Stage Hybrid Transmission Brakes Front Ventilated Disc Brakes Rear Ventilated Disc Brakes Suspension Front Independent, Double Joint High-Mount Multilink with Air Suspension Rear Independent, Double Joint Multilink with Air Suspension
Overall Length 5,235 mm Width 1,900 mm Height 1,450 mm Wheelbase 3,125 mm Weight Curb Weight 2,410 - 2,760 kg
WHEELS AND TIRES
245 / 45 R20 Noise Reduction Wheels Run Flat Tires
SMART Key Entry System Auto Rain Sensor Cruise Control Drive Mode Select Switch (ECO / COMFORT / NORMAL / SPORT S / SPORT S+ / CUSTOM) Lexus Navigation System Lexus Remote Touch Controller Bluetooth Telephone Connectivity 3-spoke Wood and Leather Steering Wheel with Controls
USB / iPod Playback Function Rear 11.6" VGA Monitor 12.3" LCD Multi-display Screen AM / FM Radio Blu-ray Player Mark Levinson® Audio System with 24 Speakers
Airbag System Driver and Front Passenger Airbags Driver and Front Passenger Knee Airbags Driver and Front Passenger Side Airbags Front and Rear Seat Curtain Shield Airbags Rear Seat Side Airbags Ottoman Cushion Airbag Lighting LED Headlights LED Daytime Running Lamps (DRL) Adaptive Front-lighting System (AFS) Headlight Auto-leveling LED Front Fog Lamps Rear Fog Lamps
Blind Spot Monitor (BSM) Hill-start Assist Control Traction Control (TRC) Vehicle Dynamics Integrated Management (VDIM) Variable Gear Ratio Steering (VGRS) Electric Power Steering (EPS) Vehicle Stability Control (VSC) Anti-lock Brake System (ABS) Electronically Controlled Brake System (ECB) Lexus Parking Assist System with Rear View Camera Lexus Parking Assist Sensors (10 Sensors) High Rigid Body Structure with Front and Rear Crumple Zones Pedestrian Protection Performance Side Impact Compatible Structure Child Restraint System (CRS) 3-point Seatbelts with Height Adjustable Anchors, Pretensioners and Force Limiters Brake Hold Function Anti-theft System with Siren
Moonroof Dynamic LED Interior Illumination Air Suspension Door Trim, Instrument Panel and Console Box Wood Leather Instrument Panel with Color Stitching Lexus Premium Analog Clock Lexus Climate Concierge Nanoe System Rear Centre Armrest with Integrated Audio and Air Conditioner Control Switch All Power Sunshades Power Trunk Lid with Kick Sensor and Easy Closer Electrochromic (Auto-dimming) Inside Rear View Mirror 4-zone Independent Auto Temperature Control Air Conditioner 12-zone Multi Blower Air Purifier Door Pockets Seating Original Factory-fitted Genuine Semi-aniline Seats Driver and Front Passenger Power Adjustable Seats Seat Lumbar Support Pelvic Support Ottoman Seat Driver and Passenger Memory Seats Front and Rear Seat Air Conditioner Rear Seat Heater Infrared Rear Seat Body Temperature Sensor
